9.BLINKING GRAPHIC SYMBOLS

4.Jam Symbols (Cont.)

Finisher

Procedure for releasing the paper misfeed in the Hole Punch Unit. If the Hole Punch Unit is not installed,

this procedure is not necessary.

Procedure for releasing the paper misfeed in the Inserter Unit. If the Inserter Unit is not installed, this pro-

cedure is not necessary.

Procedure for releasing the paper misfeed in the saddle stitch unit. If the Saddle Stitch Finisher is not

installed, this procedure is not necessary.

While pressing the button, separate the

finishing device from the equipment.

(See  P.274 for cautionary points regarding separation/

installation and moving of the options.)

Open the cover of the Hole Punch Unit.

Rotate the knob to locate the triangle

mark within the indicated area on the

label.
