8.JOB STATUS

6.Error Code (Cont.)

A290 Limit over error Number of prints has exceeded the one specified with the

department code and user code at the same time. Clear the

limit counter.

A291 Limit over error Number of prints has exceeded the one specified with the user

code. Clear the limit counter.

A292 Limit over error Number of prints has exceeded the one specified with the

department code. Clear the limit counter.

Error code Problem What to do
