231

2. Confirming Print Job Status

You can confirm the status of the print job. The following information is displayed in a list.

User Name: Name of user for whom the job was registered

Date, Time: Date and time the job was registered

Paper: Paper size to be printed

Pages: Number of pages to be printed

Sets: Number of sets to be printed

Status: Status of jobs or specified time for “Delayed TX Reservation” setting

4 jobs are displayed in 1 page. Up to 250 pages (1000 jobs) can be displayed. When you want to confirm

the 5th and following jobs, press the [Next] button, and when you want to return to the previous page,

press the [Prev] button.
