224

7.TEMPLATE

5. Deleting User Groups or Templates

Unnecessary user groups and templates can be deleted. If a user group is deleted, all templates in the

user group are also deleted.

Deleting a user group

Press the [REGISTRATION] button on the touch panel.

Select the user group you want to delete, and then press the

[DELETE] button.

• If the desired user group is not displayed on the menu, press the [Prev] or [Next] button to switch the menu.

• To display the applicable menu immediately, key in the user group number.

Press the [TEMPLATE] button on the con-

trol panel.
