Operation Manual

167
5
4
Adjust the tab width and the shift width using the [0 mm] or [30 mm]
button, and then press the [ENTER] button.
• Press [TAB EXTENSION] or [SHIFT MARGIN] to switch the item to be set.
• The initial value is set to 13 mm for both the tab width and the shift width.
• The default setting value can be changed for both the tab width and the shift width. For details, refer to the
User Functions Guide.
Range of the tab width and shift width
The range of the tab width and the shift width is different between when the tab paper is set in the
drawer and when it is set on the bypass tray.
Measuring the tab width and shift width
The tab width and the shift width can be measured by the scale on the left side and rear side of the
original glass. The marks of the original scale have a 2 mm pitch.
• Measuring the tab width
Place tab paper on the original glass to measure the tab width.
• Measuring the shift width
Place the original on the original glass to measure the shift width.
Tab width Shift width
Drawer 12 to 17 mm 0 to 30 mm
Bypass tray 10 to 20 mm 0 to 30mm
Original scale
Align the tab paper with
the original scale
Tab width
Original scale
Align the original
with the
original scale
Shift width
