4. Duplex Copying

The following 5 combinations are available for duplex copying.

1. 1-sided original -> 1-sided copy (default setting at installation)

2. 1-sided original -> 2-sided copy

3. 2-sided original -> 2-sided copy

4. 2-sided original -> 1-sided copy

5. Book-type original -> 2-sided copy

• Duplex copying is available for plain paper (64 to 80 g/m

), thick 1 paper (- 105 g/m

), thick 2 paper (-

163 g/m

) and thick 3 paper (- 209 g/m
