3.SETTING OF BASIC COPY MODES

3.Selecting Finishing Modes (Cont.)

Number of punch holes and available paper sizes

Since the number of punch holes and the distance between the holes vary depending on the country/

region, purchase a hole punch unit that meets your requirements. (For details, consult your service techni-

cian.)

Number of punch holes

and hole diameter

Available paper sizes

MJ-6003E

(Japan and most of Europe)

2 holes

(6.5 mm dia.)

A3, A4, A4-R, B4, B5, B5-R, FOLIO, LD,

LG, LT, LT-R, COMP

MJ-6003N

(North America)

2/3 holes switchable

(8.0 mm dia.)

2 holes: LG, LT-R

3 holes: A3, A4, LD, LT

MJ-6003F

(France)

4 holes

(6.5 mm dia.; 80 mm pitch)

A3, A4, LD, LT

MJ-6003S

(Sweden)

4 holes

(6.5 mm dia.; 70 mm,

21 mm pitch)

A3, A4, A4-R, B4, B5, B5-R, FOLIO, LD,

LG, LT-R, COMP
