Table Video modes (Portrait)
Video Type Resolution Character LCD CRT Scanning
mode matrix colors colors frequency
(pels) Vertical
0, 1 VGA 25 x 40 8 x 8 16 of 256K 16 of 256K 70Hz
Text Characters
2, 3 VGA 25 x 80 8 x 8 16 of 256K 16 of 256K 70Hz
Text Characters
0*, 1* VGA 25 x 40 8 x 14 16 of 256K 16 of 256K 70Hz
Text Characters
2*, 3* VGA 25 x 80 8 x 14 16 of 256K 16 of 256K 70Hz
Text Characters
0+, 1+ VGA 25 x 40 8(9) x 16 16 of 256K 16 of 256K 70Hz
Text Characters
2+, 3+ VGA 25 x 80 8(9) x 16 16 of 256K 16 of 256K 70Hz
Text Characters
4, 5 VGA 200 x 320 8 x 8 4 of 256K 4 of 256K 70Hz
Grph Pixels
6 VGA 200 x 640 8 x 8 2 of 256K 2 of 256K 70Hz
Grph Pixels
7 VGA 25 x 80 8(9) x 14 Mono Mono 70Hz
Text Characters
7
+ VGA 25 x 80 8(9) x 16 Mono Mono 70Hz
Text Characters
D VGA 200 x 320 8 x 8 16 of 256K 16 of 256K 70Hz
Grph Pixels
E VGA 200 x 640 8 x 8 16 of 256K 16 of 256K 70Hz
Grph Pixels
F VGA 350 x 640 8 x 14 Mono Mono 70Hz
Grph Pixels
10 VGA 350 x 640 8 x 14 16 of 256K 16 of 256K 70Hz
Grph Pixels
11 VGA 480 x 640 8 x 16 2 of 256K 2 of 256K 60Hz
Grph Pixels
