User Manual

B-3
A
PPENDIX
B
Table Video modes continued (Landscape)
Video Type Resolution Character LCD CRT Scanning
mode matrix colors colors frequency
(pels) Vertical
D VGA 320 x 200 8 x 8 16 of 256K 16 of 256K 70Hz
Grph Pixels
E VGA 640 x 200 8 x 8 16 of 256K 16 of 256K 70Hz
Grph Pixels
F VGA 640 x 350 8 x 14 Mono Mono 70Hz
Grph Pixels
10 VGA 640 x 350 8 x 14 16 of 256K 16 of 256K 70Hz
Grph Pixels
11 VGA 640 x 480 8 x 16 2 of 256K 2 of 256K 60Hz
Grph Pixels
12 VGA 640 x 480 8 x 16 16 of 256K 16 of 256K 60Hz
Grph Pixels
13 VGA 320 x 200 8 x 8 256 of 256K 256 of 256K 70Hz
Grph Pixels
SVGA 640 x 480 256 of 256K 256 of 256K 60Hz
Grph Pixels 75Hz
85Hz
SVGA 800 x 600 256 of 256K 256 of 256K 60Hz
Grph Pixels 75Hz
85Hz
SVGA 1024 x 768 256 of 256K 256 of 256K 60Hz
Grph Pixels 75Hz
85Hz
SVGA 1280 x 1024 256 of 256K 256 of 256K 60Hz
Grph Pixels 75Hz
85Hz
SVGA 1600 x 1200 256 of 256K 256 of 256K 60Hz
Grph Pixels
Appendix B
