9.2 Parent unit

9.2.3 Recharging batteries

With the enclosed rechargeable battery pack or 3 x AAA NiMh rechargeable batteries (not

supplied) installed, the batteries can be charged with the included charger(DC 7,5V /

200mA).

• Plug the small plug of the adapter into the charger jack

on the top of the unit and the other end in the electrical

socket.

• Make sure that the unit is switched off in order to charge

the batteries properly.

NOTE: It takes approximately 12 to 14 hours to fully charge the batteries (with

600mAh).

9.2.1 Removing/Installing the Belt Clip

1 To remove the clip from the unit, push

the belt clip (B) towards the antenna,

while pulling the belt clip tab away from

the unit (A).

2 When re-installing the belt clip, a click

indicates the Belt Clip is locked into

position.

9.2.2 Battery Installation

1 Remove the belt clip (See chapter

9.2.1 ).

2 Pull the battery door tab down (C) and

slide the battery cover away from the

antenna. (D)

3 Install the rechargeable battery pack

following the polarity as shown. Ensure

that the metal contacts on the site are

facing outwards from the radio to

connect on the battery door.(E)

4 Re-install the Battery Cover and Belt

Clip (See chapter 9.2.1 ).

Note: Instead of the supplied battery pack, the

PMR can be used with 3xAAA NiMh batteries.

Follow the polarity as shown in the battery

compartment when installing.

Only use the included AC/DC ADAPTER with “AAA” rechargeable

batteries. Do not charge this unit when regular “AAA” ‘LR03’ alkaline

batteries are installed.

Do not connect other chargers. This may damage your device.
