User guide

15
TOPCOM Babytalker 1010
ENGLISH
23 Technical specifications
Channels
Sub-code
Frequency
Range
Batteries
Transmission Power
Modulation Type
Channel spacing
Power Adapter
8
CTCTSS
446.00625MHz - 446.09375 MHz
Up to 2 Km (Open field)
Baby Unit: 4 x AAA ‘LR03’ Alkaline batteries
Parent Unit: 4 x AAA rechargeable batteries
=< 500mW ERP
FM - F3E
12,5 kHz
Baby Unit: DC 10V/300mA
Parent Unit: DC 7,5V/200mA
Memory Location PMR channel Number CTCSS frequency
M1 1 189,9Hz
M2 2 189,9Hz
M3 3 189,9Hz
M4 4 189,9Hz
M5 5 189,9Hz
M6 6 189,9Hz
M7 7 189,9Hz
M8 8 189,9Hz
M9 1 183,5Hz
M10 2 183,5Hz
M11 3 183,5Hz
M12 4 183,5Hz
M13 5 183,5Hz
M14 6 183,5Hz
M15 7 183,5Hz
