User's Guide

2
Card Reader
2. Product Specifications
2-1. General Specifications
Communication
Interface
RS232/PULSE
Card type
Contact card(ISO 7816)、non-contact card
(Mifare1 S70)
Installation site Indoors
2-2. Electronic Specifications
Input power +12V DC
Power Consumption
Standby:1.5~1.6W
Working:2.3W
Max.:2.5W
Temperature Range (° C)
Ambient: 0~60
Storage:-10~80
Humidity:20~70%RH(no condensation)
2-3. Machine Specifications
Weight 229 ±12g
Dimension 133 x 92 x 75 mm
Screen Size 1.8 Inch Screen
3. Product content
Main CMS 505( non-contact card )
Accessories
Manual*1
Wires (Check page…)
Screw set
CMS100H Adapter board(Optional)
Metal Frame Sticker (Purchase)
Metal Frame (Purchase)
