8
Card Reader
( J4 )
2WIR-CMS300C-00
PIN NO COLOR PIN DEFINE
PIN1 RED
+12V DC
PIN2 ORANGE GND
PIN3 YELLOW NC
NC
NC
NCPIN4 GREEN
PIN5 BLUE
PIN6 PURPLE
PIN NO COLOR PIN DEFINE
PIN1 YELLOW NC
PIN2 GREEN NC
PIN5 RED
+12V DC
PIN7 BLUE NC
PIN8 PURPLE NC
PIN9 ORANGE GND
WEL-R7U02
