DESIGN CONCERNS!
The following sections provide information on designing with the RN-171-XV module.
Powering the Module
Apply ONLY 3.3 V ±10% regulated power to pin 1 (VDD) and pin 10 (ground). The module does not have an on-board
voltage regulator and MUST be powered from a regulated 3.3-V power supply.
Antenna
The RN-171-XV ships with a wire antenna. Custom antenna configurations such as chip, U.FL., and reverse polarity SMA
connectors are available with extended lead times.
ORDERING INFORMATION
Table 7 provides ordering information. Table 8 provides information on related products.
Table 7. Ordering Information
Part Number
Description
RN-171-XV-W
Standard configuration, industrial temperature (-40
o
C to +85
o
C) 802.15.4 replacement solution with ¼
inch wire antenna.
RN-171-XV-U
Custom configuration, industrial temperature (-40
o
C to +85
o
C) 802.15.4 replacement solution with
U.FL. connector.
RN-171-XV-S
Custom configuration, industrial temperature (-40
o
C to +85
o
C) 802.15.4 replacement solution with a
reverse polarity SMA connector.
Table 8. Related Products
Part Number
Description
RN-XV-RD2
Two-relay evaluation board for the RN-171-XV.
RN-XV-RD1
One-relay evaluation board for the RN-171-XV.
Go to http://www.rovingnetworks.com for current pricing and a list of distributors carrying Roving Networks products.
! !
