Data Sheet

!
www.rovingnetworks.com Version 1.04 10/29/2012 2
RN- 171-XV-DS
OVERVIEW
• Host data rates up to 460 Kbps over the UART
• Intelligent built-in power management with programmable wakeup events (timers and I/O)
• Real-time clock for time stamping, auto-sleep, and auto-wakeup modes
• Configuration over Wi-Fi or UART using simple ASCII commands
• Supports over the air firmware upgrade via FTP
• Secure Wi-Fi authentication via WEP, WPA-PSK (TKIP), and WPA2-PSK
• Built-in networking applications: DHCP, DNS, ARP, ICMP UDP, Telnet, FTP client, and HTML client
• Configurable transmit power of 0 to 12 dBm
• WPS mode for easy and secure wireless setup
• Built-in HTML web client to send GPIO, UART, and sensor data to remote web servers
The module’s size is:
• Size—0.96” x 1.15”
• Weight—5.5 g
Tables 1 through 5 provide detailed specifications for the module.
Table 1. Environmental Conditions
Parameter
RN-171-XV
Temperature Range (Operating)
-40
o
C ~ +85
o
C
Temperature Range (Storage)
-40
o
C ~ +85
o
C
Relative Humidity (Operating)
≤90%
Relative Humidity (Storage)
≤90%
!
Table 2. Electrical Characteristics
Supply Voltage
Min
Typ.
Max.
Units
Input Power
3.0
3.3
3.7
V
Power Consumption
Sleep
4
uA
Standby (doze)
15
mA
Connected (idle, RX)
40
mA
Connected (TX)
180 at 10 dBm
mA
!
!
