Classic 50 Move+ Instruction Manual W300 Classic 50 Move+ 3.17.
Table of Contents IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS ................................................................................. 3 WHAT’S INCLUDED........................................................................................................................................ 3 WATCH FEATURES AND BUTTON OPERATION ............................................................................................. 3 WEARING YOUR TIMEX IRONMAN CLASSIC 50 MOVE+ .....................................
NFC SYNC............................................................................................................................................. 16 BLUETOOTH SMART SYNC................................................................................................................... 17 TRANSFERRING DATA FROM YOUR WATCH TO THE APP ....................................................................... 18 TIMEX CONNECTED NAVIGATION PANE ....................................................................
Thank you for purchasing the TIMEX IRONMAN Classic 50 Move+. http://www.timex.com/classic50move IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS 1. This is not a medical device and is not recommended for use by persons with serious heart conditions. You should always consult your physician before beginning or modifying an exercise program. 2. Consulting the information on the display while moving is unsafe and distracting, and could result in accident or collision.
Press Mode button repeatedly to step through modes: Chrono, Interval Timer, Timer, Review, Setup, Appointment, Alarms, Sync. Press Mode button to exit current mode and return to Time of Day.
BATTERY Your TIMEX IRONMAN Classic 50 Move+ is powered by a user replaceable coin cell battery (CR2025), however Timex strongly recommends that a retailer or jeweler replace the battery. The battery in your TIMEX IRONMAN Classic 50 Move+ will last approximately 15 months. Battery life estimates are based on certain assumptions regarding usage; battery life may vary depending on actual usage. DO NOT DISPOSE OF BATTERY IN FIRE. DO NOT RECHARGE. KEEP LOOSE BATTERIES AWAY FROM CHILDREN.
ON THE WATCH Your watch can be setup using two methods: TIMEX Connected app (the easiest method) or The setup functions directly in the watch SETTING THE TIME/DATE Setting the time manually on the watch will clear all appointments previously loaded to the watch. 1. From the Time of Day screen, press and hold the Set/Recall button. 2. Push the Start/Split button to select first or second time zone. 3.
ALARMS Your TIMEX IRONMAN Classic 50 Move+ is equipped with three alarms. When alarms are activated, the Indiglo® night-light and alarm icon will flash and you will get an audible alert; push any button to silence those alerts. If no button is pressed the alarm will sound for 20 seconds and repeat once after 5 minutes. To set your alarms: 1. Push the Mode button until ALARMS is on the top of the display. 2.
INDIGLO® NIGHT-LIGHT Electroluminescent technology used in the INDIGLO night-light illuminates the entire watch face for easy viewing at night and in low light conditions. Push the INDIGLO button to illuminate watch display for 3-4 seconds when the watch is not in the Setting state, or 6-7 seconds otherwise.
. To delete the latest stored workout, push and hold the Stop/Reset button for three seconds. To delete all stored workouts, push and hold the Stop/Reset button for six seconds. NOTES: Upon entering Chrono mode, a message will show on the watch face that prompts you to the number of laps that can be stored before Chrono memory is filled; if the Chrono memory is full you will see “MEMORY FULL” displayed. See the Review section of this manual for information on deleting workouts.
7. Push the Mode button, then push the Start/Split and/or Stop/Reset buttons to select Repeat at End or Stop at End. When appropriate selection is on screen, push Mode button. Stop at End should be used when you DON’T want the interval to repeat. Repeat at End should be used when you DO want the interval to repeat. 8. If you want your interval to include more than one segment, push the Start/Split button to make adjustments to INT 2, then push the Mode button. 9.
TIMER Timer mode provides a countdown timer with alert. Timer counts down every second from countdown time. Your TIMEX IRONMAN Classic 50 Move+ will beep and the night-light will flash when the countdown timer ends (timer reaches zero), push any button to silence the alert. You are given two options for your countdown timer: Stop at End (one time countdown timer) and Repeat at End (will repeat indefinitely). SETTING THE TIMER 1. Push the Mode button until you see TIMER on the screen. 2.
1. From the Time of Day screen, push the Mode button until you see Review on the screen. 2. Push the Start/Split and/or Stop/Reset buttons to cycle through the review options and select the data you want to review: ACTVTY (Daily Activity), CHRONO (Chrono Workout) and INTTMR (Interval Workout). 3. When you have selected the metrics you want to review, push the Set/Recall button. 4. If available, the watch will list all days saved in the memory.
11. Use the Start/Split button to make your NFC selection: On (allows the watch to communicate with NFC antennas) or Off. 12. Once all selections have been made, push the Set/Recall button to exit and save settings. 13. Push the Mode button to return to the Time of Day screen or push the Start/Split button to proceed to the next Setup menu option. USER SETUP 1. 2. 3. 4. 5. 6. 7. 8. From the Time of Day screen, push the Mode button until you see Setup on the screen.
APPOINTMENTS Your TIMEX IRONMAN Classic 50 Move+ can hold up to 50 appointments. Please see the TIMEX Connected app instructions for detailed instructions about managing appointments. Your TIMEX IRONMAN Classic 50 Move+ will alert you when you have an upcoming appointment. Alerts will be 2 hours, 1 hour, 30 minutes or 15 minutes before the appointment time (based on the reminder setting tied to the appointment).
SYNC Smartphone Sync allows your TIMEX IRONMAN Classic 50 Move+ to connect to a compatible Smartphone via Bluetooth Low Energy technology. Access the Sync menu to initiate the Bluetooth Low Energy connection between your watch and your TIMEX Connected app. 1. From the Time of Day screen, push the Mode button until you see Sync on the screen. 2. Push the Start/Split button to initiate the data transfer process. a. When the transfer has been completed successfully you will see Sync Ok on the screen. b.
THE TIMEX CONNECTED APP INSTALLING THE TIMEX CONNECTED PHONE APP The TIMEX Connected app requires the following OS: Android: 4.4.2 or higher, NFC capable device or Bluetooth Smart compatible iOS: iOS 8.1.2 or higher, Bluetooth Smart compatible The TIMEX Connected app provides the easiest and most convenient method to setup and configure your TIMEX IRONMAN Classic 50 Move+. Download and install the TIMEX Connected app for iOS from the iTunes app store, or for Android, from the Google Play app store.
Keep Watch Settings should be used if you want to maintain any settings adjusted on the physical watch face. Keep App Settings should be used if you want to maintain any settings adjusted in the app. 9. If Keep App Settings is selected, you will need to touch the watch to the back plate of your Android device. 10. On the Initial Setup screen, enter the device registration information (First Name, Last Name, Email Address and Zip Code).
TRANSFERRING DATA FROM YOUR WATCH TO THE APP Your TIMEX IRONMAN Classic 50 Move+ offers a discrete connection to the TIMEX Connected app. This means your watch must be manually synced with the app each time you want to transfer data between the app and the watch. To transfer data using Bluetooth Smart: 1. 2. 3. 4. From the Home Page, tap the watch icon in the upper right-hand corner. On the watch, push the Mode button until you see “SYNC PHONE/PRESS START” on the screen.
TIMEX CONNECTED NAVIGATION PANE Access Navigation Pane from any page Home Workouts Watch Control Calendar App Settings About Help TIMEX CONNECTED HOME PAGE Bluetooth Smart Sync Last Sync with Watch Workout Summary/Reports Steps Taken Today Calories Burned Today Total Distance Traveled Today Workouts Watch Control App Settings Calendars NOTE: Steps Taken, Calories Burned and Total Distance data is displayed above a color coded bar. This bar represents the goals set for each activity data metric.
WORKOUT SUMMARY/REPORTS PAGE Tap the Date Selector Icon to reveal the Date Selector Tool. This will show you the activity data for the selected day. Data can be viewed by day, week, month or year.
WORKOUTS LIST PAGE Workout Graphs Icon, use to view Workout reports by 1 week, 2 weeks, 30 days or 60 days Selector Icon Workout Uploaded to 3 Party Site rd Tap the Workout to view the details of the workout file Total number of Workouts TIMEX® IRONMAN® Classic 50 Move+ Owner’s Manual Page 21
WORKOUT DETAILS PAGE Tap these icons to quickly access that portion of the workout details Workout options: Rename Workout Upload Workout Share Workout Delete Workout View graphical representation of Workout TIMEX® IRONMAN® Classic 50 Move+ Owner’s Manual Page 22
WORKOUT DETAILS GRAPHS Graphical representation on a Bar Chart or XY Plot Graphical comparison of two saved Workout files TIMEX® IRONMAN® Classic 50 Move+ Owner’s Manual Page 23
UPLOADING WORKOUTS TO 3rd PARTY SITES 1. From the Workout List Page, tap the Selector Tool icon 2. Tap the circles next to the Workout files that are to be transferred 3. Tap the Upload button to reveal the Upload options. 4.
5. The app will automatically bring you to the App Settings Page, tap ADD SITE rd 6. Tap the 3 Party site you wish to share your Workouts with 7. You can choose to automatically upload all Workouts by turning Auto Upload ON 8. Tap the Connect button.
WATCH CONTROL Activity Tracking On/Off (3D accelerometer) Medium (default) Low High Off Steps Distance Calories Time Zone 1 (T1) Settings Time Format: 12 Hour 24 Hour Time Zone 2 (T2) Settings Time Sync: Follow Phone: Watch will take time from the phone, which adjusts automatically after traveling into a new time zone* Time Zone: User selects the time zone to be used for T2 Manual: User manually sets the time for T2 Date Format: Month-Day Day-Month Time Format: 12 Hour 24 Hour Date
Stop at End Repeat at End Customize interval 1 and 2 Repeat Function for Both Intervals Stop at End Repeat at End Available Frequencies Daily Weekdays Weekends Monday Tuesday Wednesday Thursday Friday Saturday Sunday Audible alert on the watch at each hour Any button press on the watch will activate the Indiglo light Audible alert on the watch with each button press Units display on the watch TIMEX® IRONMAN® Classic 50 Move+ Owner’s Manual Page 27
CALENDARS Selector Icon Meeting Subject Meeting Date Meeting Time Pre-notification timing Meeting Alert Edit Tool After using the Selector Icon Ability to select which calendars you want to use for calendar entries Ability to select multiple calendar entries to exclude Ability to select multiple calendar entries to set alarms Takes you to the Calendar Settings under App Settings TIMEX® IRONMAN® Classic 50 Move+ Owner’s Manual Page 28
After using the Meeting Alert Edit Tool Watch will not provide audible alert for this calendar entry Instant 15 minutes 30 minutes 45 minutes 60 minutes 120 minutes TIMEX® IRONMAN® Classic 50 Move+ Owner’s Manual Page 29
APP SETTINGS Will show in the Bluetooth devices list Allows the user to select an image to tie to the workout when sharing to social networks Detection of an NFC sensor will automatically open the TIMEX Connected app Makes meetings/appointments available for view without data connection Re-activates all meetings/appointments Removes all custom alarms 1 month 6 months 1 year 2 years All Best Lap Average Lap Workout Date Number of Laps Total Time Chrono/Interval Lap/Split Split/Lap App will remove workou
ABOUT App Version and Build Number HELP The help link will take you to the Frequently Asked Questions for the TIMEX Connected app. You can also access Help to view the End User License Agreement.
FCC NOTICE (U.S.) / IC NOTICE (CANADA) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada licence-exempt RSS standard(s).
DECLARATION OF CONFORMITY Manufacturers Name: Timex Group USA, Inc.
