Instruction Manual

8
General RCD Specifi cations
Voltage: 230V AC 50Hz
Max Current: Fully complies with the current
rating required by BS1363
Rated Trip Current: 30mA
RCD Type: Double Pole, suitable for
2 and 3 wire applications
Breaking Capacity: 250A (Earth leakage)
Through Fault Withstand: 1500A
Operating Temperature Range: -5° to 40°C
Trip Speed: Less than 40msec at 150mA
residual current
Fully Complies With: BS7288 & BS1363
Minimum Box Depth Required: 25mm
Fixed Cable Capacity: 1 x 8mm
2
or 2 x 4mm
2
or 3 x 2.5mm
2
Flexible Cable Capacity: 10.5mm diameter maximum
(RCD10WPV only)
