Installation Guide

Page 3
1 2
• Posts must be
positioned no more
than 8’ on center, and
must be plumb.
• Trim 4x4 Post to a
min of 35 1/2” (for
36”) and 41 1/4” (for
42) above finished
deck surface.
• Slide uncut Post
Sleeves over 4x4
posts. Do not force.
CUT POSTS AND
TEMPORARILY
INSTALL POST
SLEEVES
• Using provided
template, mark
Baluster locations on
one BuilderBoard, then
transfer to the other.
MARK BALUSTER
LOCATIONS
Min.
35 1/2”
MEASURE AND TRIM
BUILDERBOARDS
3
• Measure between Posts.
• Determine if a space or
Baluster will be on center.
• Cut BuilderBoards to length.
4 3/8”
Top Rail Length
Bottom Rail Length
Centerline
Baluster Centered
Space Centered
Do not cut Post Sleeves in this step.
Installing Evolutions Rail
TM
Builder Style with Metal Balusters
