Installation Guide

Page 23
INSTALL GASKET AND
GLASS PANEL
9
10
INSTALL TOP RAIL AND
TOP GLASS CHANNEL
• Fit Bottom Gasket onto
bottom of glass panel
and fit assembly into
channel in Bottom Glass
Channel.
• Fit Gasket onto top of
glass panel, followed by
the Top Glass Channel.
• Place Top BuilderBoard
over glass panel
assembly and secure.
Top Glass Channel:
Pre-drilled holes are
on side
Pre-Drill 7/64”
#8 x 2 1/4 ”
Coated Screws
Pre-Drill 9/64”
#10 x 2” Coated
Screws
Installing Evolutions Rail
TM
Builder Style Stairs
with Glass Infill
