Installation Guide

Page 22
MEASURE AND TRIM
BOTTOM POST AND
POST SLEEVE
7
8
INSTALL BOTTOM RAIL
AND BOTTOM GLASS
CHANNEL
• Move Bottom BuilderBoard
and Bottom Glass Channel
into place and secure.
• Mark where Top
BuilderBoard meets
Bottom Post Sleeve.
• Remove Post Sleeve
and trim to stair angle.
Replace Post Sleeve.
• Use Post Sleeve to mark
the angle of cut on Post.
Remove Post Sleeve.
• Using a straight edge,
draw a line roughly 1/8”
below previous mark on
Post.
• Trim Post at lower line.
• Replace Post Sleeve.
• Slide on Post Skirts.
Bottom Glass Channel:
Pre-drilled holes are in channel
Pre-Drill 9/64”
#10 x 2” Coated Screws
Pre-Drill 7/64”
#8 x 1” Coated Screws
Installing Evolutions Rail
TM
Builder Style Stairs
with Glass Infill
