Installation Guide

Installing Evolutions Rail
TM
Builder Style with Glass Infill
Page 13
DIMENSIONAL CONSTRAINTS
FOR STRAIGHT SECTION
DIMENSIONAL CONSTRAINTS
FOR STAIR SECTION
Max of 63”
Max of 63”
Min 24” for 36”
May be taller for
stairs
Min 24”
for 36”
Glass should
be 1/4” thick
Glass should
be 1/4” thick
Min of 2”
Max of 4”
Min of 2”
Max of 4”
