Installation Guide

Page 10
MEASURE AND TRIM
BOTTOM POST AND
POST SLEEVE
7
8
INSTALL BOTTOM
RAIL, BALUSTERS,
AND TOP RAIL
• Move Bottom
BuilderBoard into place
and secure. Pre-Drill
through Brackets with
9/64” bit.
• Place Balusters onto
Baluster Connectors.
• Mark where Top
BuilderBoard meets
Bottom Post Sleeve.
• Remove Post Sleeve
and trim to stair angle.
Replace Post Sleeve.
• Use Post Sleeve to mark
the angle of cut on Post.
Remove Post Sleeve.
• Using a straight edge,
draw a line roughly 1/8”
below previous mark on
Post.
• Trim Post at lower line.
• Replace Post Sleeve.
• Slide on Post Skirts.
For ease of connecting Balusters,
attach only 1 end of Top Builder-
Board and rotate down, fitting one
Baluster at a time.
Pre-Drill 9/64”
#10 x 2” Coated Screws
Installing Evolutions Rail
TM
Builder Style Stairs
with Metal Balusters
