SPECIFICATIONS
CATEGORY OF CABLE
• Unshielded communication cable with RJ-11 and RJ-45 connectors.
• Ethernet 10 Base-T, Token Ring, EIA/TIA-568A/B, AT&T 258A, and
USOC.
• 50 or 75Ω coaxial cable with F connectors.
• 50 or 75Ω coaxial cable with BNC connectors. Must use F to BNC
adapters (not included).
Maximum testing length for all cable types is 1,000 feet.
MULTIPLE FUNCTIONS
• Testing cables before or after their installation.
• Identify up to 7 different cables (location).
• Mapping Function (identifies pin-to-pin configuration).
• Cable identification (straight or cross-pinning).
• Pair identification (straight or cross-pinning).
• Open/short wiring test.
• Low battery indicator
• Auto power-off function
For Location Function - 2 min.
For Mapping Function - 30 sec.
DIMENSIONS
• Cable Tracer: 2.60” / 66mm (W) x 5.75” / 146mm (H) x
1.31” / 33.2 mm (D) (without holster)
• Remote Identifier: .83” / 21.1mm (W) x 2.44” / 62mm (H) x 0.87” / 22mm (D)
WEIGHT
• Cable Tracer: 4.5 oz. / 128 g. (without battery and holster)
• Remote Identifier: 0.68 oz. / 19.4 g.
ENVIRONMENTAL CONDITIONS
• Operating Temperature: -20
O
C to 55
O
C / -4
O
F to 131
O
F
• Storage Temperature: -40
O
C to 60
O
C / -40
O
F to 140
O
F
• Relative Humidity: 0% to 90% (0
O
C / 32
O
F to 35
O
C / 95
O
F)
0% to 70% (35
O
C / 95
O
F to 55
O
C / 131
O
F)
BATTERY TYPE
• 9V, NEDA 1604 or 6F22 or 006P
