Assembly Instruction

Figure 7
STEP 7 Attach Fixture Chain to Canopy
Chain Loop and Fixture Loop
-
A. Adjust the Fixture Chain (H) to your desired length by
removing the links if needed. You may need to use plier
to open the chain links. If so, put a cloth over the chain
to protect the finish from the pliers.
B. Attach one end of the Fixture Chain (H) onto the
Canopy Chain Loop (F) and then attach the other end of
the Fixture Chain (H) onto the Fixture Loop on the top of
the Fixture Loop Assembly (J).
Fixture Loop
Canopy Chain Loop
Fixture Chain
Supply Wire and
Ground Wire
Fixture Loop
Assembly
Figure 8
Supply Wire
and Ground Wire
Fixture Chain
Canopy Chain
Loop
STEP 8 Pass Supply Wires through Fixture
Chain
-
A. Pull the Supply Wires and Ground Wire up through the
Fixture Chain (H) alternating links. Push the wires up
through the Canopy Chain Loop (F) into the outlet box.
Assembly Instruction Sheet
5of6
Thank you for purchasing this product.
Need assistance with parts or assembly? Call our customer service or visit us on-line
