Data Sheet

Conrad Electronic
Artikelnummer: 189276
Rev. B
Datenblatt thermofol - Wärmefolie
Datasheet thermofol – heater
Nennspannung: 230 V
Nominal Voltage:
Nennleistung: 7 W
Effective Output:
Abmessungen: 190 mm x 260 mm
Dimensions: 7.48” x 10.24”
Oberflächentemperatur*: ca. 30 °C
Surface temperature**: approx. 86 °F
Regelthermostat: ohne
Thermostat: without
Sicherheitsthermostat: ohne
Safety Thermostat: without
Dicke: ca. 1,5 mm
Thickness: approx. 0.059“
Elektro-Anschluss: ca. 1,5 m Kabel mit Euro-Stecker
Electrical Connection: approx.. 1.5 m (59.06”) cable with euro plug
Temperaturbereich: Dauerbelastung -40 °C (-40 °F) bis max. +95 °C (+203 °F)
Temperature Range: Long term loading -40 °C (-40 °F) up to max. +95 °C (+203 °F)
RoHS konform: Ja
RoHS compliant: yes
Schutzrad: IP X7
Degree of Protection: IP X7
Bemerkung: Nicht in die Wärmefolie schneiden, stechen oder bohren
Comment: Do not cut, pierce or drill into heater
