3. Technical Data
Dimensions H x W x D mm 45 x 17,5 x 60
Distributor section mm 46 x 18,5
Connection see unit imprint
Switching capacity AC
– ohmic load (VDE, IEC) cos phi 1 16 A/230 V
– inductive load cos phi 0,6 10 A/230 V
– incandescent lamp load 2300 W
– fluorescent lamp in DUO circuit 20 x 2 x 58 W
– fluorescent lamp, parallel-compensated 20 x 58 W
– fluorescent lamp, series-compensated 40 x 58 W
– electronic ballast 5 x 20 W
– conventional ballast 1500 W
Switching contact N/O contact
Ambient temperature –10° C … +55° C
Protection class/type II/IP 20
Adjustment range 0.5 … 99.5 minutes
Glow lamp load max. 50 x 1 mA
ON period 100% on-load factor
Hand switch yes
Resettable immediately
Attachment captive +/– screws
Connection type 3/4 wire connection
Diagnosis functions yes
Caretaker function = 1 hour press approx. 3 seconds
Options/prewarning yes
