Instruction Manual

Rated voltage: 220-240 V~ +/-10%
Frequency: 50/60Hz
Rated current at 230 V~ cos
ϕ = 1: 16A
Device consumption: < 1 W
Contact type: NO
Contact: Not potencial free
Time adjustment range: 30 sec. … 20 min
Type of connection: Zero-crossing load switching
Rated load AC1: 3700 VA
Incandescent lamp load (lamps max. 200 W): 3600 W
Halogen lamp load: 3600 W
Halogen (low voltage): 1600 VA
Fluorescent lamps (EVG) (Electr. Ballast): 1000 VA
Compact fluorescent lamps (EVG): 34 x 7 W, 27 x 11 W
24 x 15 W, 22 x 23 W
Protection category (DIN EN 60529): IP20
Ambient temperature range: -10ºC…. +55ºC
Pilot lamps: max. 150 mA
Max. wires size: solid cable 1 x 4 mm²/2 x 2,5 mm²
stranded cable 1 x 2,5 mm²/2 x 1,5 mm²
Pre-Warning: DIN 18015-2
