Instructions

1514
LIFE – Wireless weather station

Caution!
 Risk of injury:
• Keep these devices and the batteries out of reach of children.
• Batteries must not be thrown into a fire, short-circuited, taken apart or recharged. Risk of explosion!
• Batteries may be hazardous if swallowed. If a battery is swallowed, this can lead to serious internal burns and death within
two hours. If you suspect a battery could have been swallowed or otherwise caught in the body, seek medical help imme-
diately.
• Batteries contain harmful acids. Low batteries should be changed as soon as possible to prevent damage caused by leak-
ing. Never use a combination of old and new batteries together, nor batteries of different types. Wear chemical-resistant
protective gloves and safety glasses when handling leaking batteries.
 Important information on product safety!
• Do not expose the device to extreme temperatures, vibrations or shocks.
• Protect it from moisture.
• The outdoor transmitter is splashproof, but not watertight. When placed outdoors, choose a shady and dry place for the
transmitter.
5. Elements
5.1 Wireless weather station (base station)
A: LCD display (Fig. 1):
A 1: Time A 2: Date
A 3: Symbol for the indoor values A 4: Indoor temperature
A 5: Indoor humidity A 6: Indoor max/min values
A 7: Symbol for the outdoor values A 8: Outdoor humidity
A 9: Outdoor temperature A 10: Channel number
A 11: Reception symbol for the outdoor transmitter A 12: Battery symbol
A 13: Outdoor max/min values A 14: Weather symbol
LIFE – Wireless weather station

B: Buttons (Fig. 1):
B 1: CH/▲ button B 2: SET button
B 3: MEM/▼ button B 4: LIGHT button
C: Housing (Fig. 2):
C 1: Wall mounting hole C 2: Battery compartment
C 3: Stand (fold out)
5.2 Transmitter (Fig. 3):
D 1: LED signal lamp D 2: Channel number
D 3: Temperature D 4: Humidity
D 5: Battery symbol D 6: Radio symbol
D 7: Wall mounting hole D 8: Battery compartment
D 9: CH 1/2/3 switch (inside battery compartment)
6. Getting started
6.1 Insert the batteries
• Place the instruments on a table at a distance of about 1.5 meters from each other. Avoid being close to possible sources
of interference such as electronic devices and radio equipment.
• Remove the protective film from the base station display.
• Open the battery compartment at the back of the base station.
• Insert three new AAA 1,5 V batteries into the battery compartment. Make sure the polarities are correct.
• Close the battery compartment again.
• All segments will be displayed briefly.
• Remove the protective film from the transmitter display.
• Open the battery compartment of the transmitter by pulling the battery compartment cover downwards (see marking) and
lift up the cover.
• Insert two new AA 1,5 V batteries, polarity as illustrated. All segments will be displayed briefly. The LED signal lamp flashes.
• Close the battery compartment again.
