Hardware Documentation

Table 29. XTR108EVM-USB Sensor Board Bill of Materials

Qty Value Ref Des Description Vendor Part Number

1 0.1µF C1 CAP CER .10UF 25V X7R 10% 0603 TDK Corporation C1608X7R1E104K

1 220pF C8 CAP CER 220PF 50V X7R 10% 0603 TDK Corporation C1608X7R1H221K

1 2.2µF C9 CAP CER 2.2UF 16V Y5V 0603 TDK Corporation C1608Y5V1C225Z

3 10000pF C10, C11, CF CAP CER 10000PF 100V X7R 10% 0603 TDK Corporation C1608X7R2A103K

1 1000pF C12 CAP CER 1000PF 50V 10% X7R 0603 Murata Electronics GRM188R71H102KA01D

1 330pF C13 CAP CERAMIC 330PF 50V NP0 0603 Yageo CC0603JRNP09BN331

1 49.9kΩ R1 RES 49.9K OHM 1/10W 1% 0603 SMD Panasonic - ECG ERJ-3EKF4992V

3 100Ω R2-R4 RES 100 OHM 1/10W 1% 0603 SMD Panasonic - ECG ERJ-3EKF1000V

1 10kΩ R5 RES 10.0K OHM 1/10W 1% 0603 SMD Panasonic - ECG ERJ-3EKF1002V

3 0Ω R7-R9 RES 0.0 OHM 1/10W 5% 0603 SMD Yageo RC0603JR-070RL

1 36.5kΩ R10 RES 36.5K OHM 1/10W 1% 0603 SMD Panasonic - ECG ERJ-3EKF3652V

1 30.1kΩ R11 RES 30.1K OHM 1/10W 1% 0603 SMD Panasonic - ECG ERJ-3EFK3012V

1 549Ω RCM RES 549 OHM 1/10W 1% 0603 SMD Panasonic - ECG ERJ-3EKF5490V

1 34kΩ RLIN RES 34K OHM 1/16W .5% 0603 SMD Susumu Co Ltd RR0816P-3402-D-52C

1 12.1kΩ RSET RES 12.1K OHM 1/16W .5% 0603 SMD Susumu Co Ltd RR0816P-1212-D-09C

1 6.34kΩ RVI RES 6.34K OHM 1/16W .5% 0603 SMD Susumu Co Ltd RR0816P-6341-D-78H

1 100.0Ω RZ1 RES 100 OHM 1/10W .1% 0603 SMD Panasonic - ECG ERA-3AEB101V

0 OMIT RZ2-RZ5, RL, R6, C2-C7 Omit; not installed N/A N/A

1 1SS355TE-17 D1 DIODE SWITCH 90V 100MA SOT-323 Rohm Semiconductor 1SS355TE-17

1 BAV99 D2 DIODE SWITCH SS DUAL 70V SOT323 ON Semiconductor BAV99RWT1G

2 Ferrite F1, F2 FERRITE 300MA 600 OHM 0603 SMD Laird-Signal Integrity Products HZ0603C601R-10

1 NFET Q1 MOSFET, N CHANNEL, DEPLETION MODE Supertex DN2540N8

1 XTR108 U1 IC 4-20MA 2-WIRE TRNSMTR 24-QSOP Texas Instruments XTR108EA

1 25C040/SN U2 IC EEPROM 4KBIT 3MHZ 8SOIC Microchip Technology 25C040/SN

1 SN74LVC1G04 U3 IC SINGLE INVERTER-GATE SC-70 Texas Instruments SN74LVC1G04DCKT

9 Pin Socket RZ1-RZ5, RCM, RLIN, RSET CONN SOCKET RCPT .014-.026 30AU Tyco Electronics 5050863-5

2 3-pin Terminal J1, J5 TERMINAL BLOCK 5MM 3POS On Shore Technology Inc ED300/3

1 DSUB15M J2 CONN DB15 MALE .318" R/A NICKEL Norcomp Inc 182-015-113R531

2 2-pin Terminal J3, J4 TERMINAL BLOCK 5MM 2POS On Shore Technology Inc ED300/2

REFout, REFin, R_set, SCK, CS1, CS2, SDIO, Vcc, Io, Vgate,

29 TP Cut to Size GND1-GND6, Iin, Vo, V/I-0 to V/I-5, R_lin, Cfilter, OPA In+, CONN. HEADER .100 SNGL 1POS Samtec TSW-101-07-G-S

OPA In–, OPAout

HEADER, 3 POSITION, SINGLE ROW, GOLD,

8 3-position Jumper JMP1-JMP8 Samtec TSW-103-07-G-S

0.100"

8 Jumper Shunts JMP1-JMP8 JUMPER SHORTING UNITS Tyco Electronics 881545-2

4 Screws N/A SCREW MACHINE PHILLIPS 4-40X3/8 B&F Fastener Supply PMS 440 0038 PH

4 Standoffs N/A STANDOFF HEX 4-40THR ALUM .500"L Keystone Electronics 2203
