Software Overview
www.ti.com
Table 23. Overscale Threshold
I
O
Overscale
V
O
Overscale Threshold
OS3 OS2 OS1 OS0 Threshold R
VI
= 6.34 kΩ
0 0 0 0 2.625 V 20.7 mA
0 0 0 1 2.6875 V 21.2 mA
0 0 1 0 2.75 V 21.7 mA
0 0 1 1 2.8125 V 22.2 mA
0 1 0 0 2.875 V 22.7 mA
0 1 0 1 2.9375 V 23.2 mA
0 1 1 0 3.0 V 23.7 mA
0 1 1 1 3.0625 V 24.2 mA
1 0 0 0 3.125 V 24.6 mA
1 0 0 1 3.1875 V 25.1 mA
1 0 1 0 3.25 V 25.6 mA
1 0 1 1 3.3125 V 26.1 mA
1 1 0 0 3.375 V 26.6 mA
1 1 0 1 3.4375 V 27.1 mA
1 1 1 0 3.5 V 27.6 mA
1 1 1 1 3.5625 V 28.1 mA
Table 24. Underscale Threshold
I
O
Underscale
V
O
Underscale Threshold
US2 US1 US0 Threshold R
VI
= 6.34 kΩ
0 0 0 450 mV 3.55 mA
0 0 1 425 mV 3.35 mA
0 1 0 400 mV 3.15 mA
0 1 1 375 mV 2.96 mA
1 0 0 350 mV 2.76 mA
1 0 1 325 mV 2.56 mA
1 1 0 300 mV 2.37 mA
1 1 1 275 mV 2.17 mA
30
XTR108EVM-USB Evaluation Board and Software Tutorial SBOU123–March 2012
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated
