Task-Specific Program Code

C-20

Example C–13. Synchronous Serial Port Continuous Mode Transmission (ssp.asm)

* File: ssp.asm *

* Function: Continuous transmit in CONTINUOUS mode *

* Internal shift clock and frame sync *

* Transmit FIFO level is set to 4 *

.title ”SSP Continuous mode” ; Title

.copy ”init.h” ; Variable and register declaration

.copy ”vector.h” ; Vector label declaration

.text

start: clrc cnf ; Map block B0 to data memory

ldp #0h ; set DP=0

setc INTM ; Disable all interrupts

splk #0000h, 60h ; Set zero wait states

out 60h, wsgr

splk #0cc0ch,60h ; reset the serial port by writing

out 60h, sspcr ; zeros at NOR/RES

splk #0cc3ch,60h ; enable Sync port, 4 word fifo,

out 60h,sspcr ; internal clocks, Continuous mode

; Use sspcr= #0cc3eh for Burst mode

splk #1717h,61h ; dummy data for tx

splk #7171h,63h

splk #0aa55h,64h

splk #55aah,62h ; transmit 55aah on tx

splk #10h,imr ; enable xinit interrupt

clrc intm ; enable INTM

out 62h,sdtr ; Xmit once to start

out 61h,sdtr ; transmit interrupts

out 63h,sdtr

out 64h,sdtr

loop: clrc xf ; clear xf flag

idle

b loop

codtx: setc xf ; set xf bit

out 62h,sdtr ; transmit 0x55aah again

out 61h,sdtr ; transmit 1717h

out 63h,sdtr ; transmit 7171h

out 64h,sdtr ; transmit aa55h

splk #0010h, ifr ; clear ifr flag

clrc intm

ret

codrx: ret

inpt1: ret

inpt23: ret

timer: ret

uart: ret

.end ; Assembler module end directive

; –optional
