Rotate Accumulator Right

ROR

7-145

Assembly Language Instructions

Syntax ROR

Operands None

Opcode

0123456789101112131415

1011000001111101

Execution Increment PC, then ...

C → ACC(31)

(ACC(0)) → C

(ACC(31:1)) → ACC(30:0)

Status Bits

Affects

This instruction is not affected by SXM.

Description The ROR instruction rotates the accumulator right one bit. The value of the

carry bit is shifted into the MSB of the accumulator, then the LSB of the accu-

mulator is shifted into the carry bit.

Words 1

Cycles for a Single ROR Instruction

ROM

DARAM SARAM External

1 1 1 1+p

Cycles for a Repeat (RPT) Execution of an ROR Instruction

ROM

DARAM SARAM External

n n n n+p

Example ROR

Before Instruction After Instruction

ACC 0 B0001235h ACC 1 5800091Ah

Cycles
