Push Low Accumulator Onto Stack

PUSH

7-141

Assembly Language Instructions

Syntax PUSH

Operands None

Opcode

0123456789101112131415

0011110001111101

Execution Increment PC, then...

Push all stack locations down one level

ACC(15:0) → TOS

Status Bits None

Description The stack values move down one level. Then, the content of the lower half of

the accumulator is copied onto the top of the hardware stack.

The hardware stack operates as a last-in, first-out stack with eight locations.

If more than eight pushes (due to a CALA, CALL, CC, PSHD, PUSH, TRAP,

INTR, or NMI instruction) occur before a pop, the first data values written are

lost with each succeeding push.

Words 1

Cycles for a Single PUSH Instruction

ROM

DARAM SARAM External

1 1 1 1+p

Cycles for a Repeat (RPT) Execution of a PUSH Instruction

ROM

DARAM SARAM External

n n n n+p

Example PUSH

Before Instruction After Instruction

ACC X 7h ACC X 7h

Stack 2h Stack 7h

5h 2h

3h 5h

0h 3h

12h 0h

86h 12h

54h 86h

3Fh 54h

Cycles
