POPD

Pop Top of Stack to Data Memory

7-138

Cycles for a Repeat (RPT) Execution of a POPD Instruction

Program

Operand ROM DARAM SARAM External

DARAM n n n n+p

SARAM n n n, n+2

†

n+p

External 2n+nd 2n+nd 2n+nd 2n+2+nd+p

†

If the operand and the code are in the same SARAM block

Example 1 POPD DAT10 ;(DP = 8)

Before Instruction After Instruction

Data Memory Data Memory

40Ah 55h 40Ah 92h

Stack 92h Stack 72h

72h 8h

8h 44h

44h 81h

81h 75h

75h 32h

32h 0AAh

0AAh 0AAh

Example 2 POPD *+,AR1
