LTD

Load TREG, Accumulate Previous Product, and Move Data

7-96

Words 1

Cycles for a Single LTD Instruction

Program

Operand ROM DARAM SARAM External

‡

DARAM 1 1 1 1+p

SARAM 1 1 1, 3

†

1+p

External 2+2d 2+2d 2+2d 5+2d+p

†

If the operand and the code are in the same SARAM block

‡

If the LTD instruction is used with external memory, the data move will not occur. (The previous

product will be accumulated, and the TREG will be loaded.)

Cycles for a Repeat (RPT) Execution of an LTD Instruction

Program

Operand ROM DARAM SARAM External

‡

DARAM n n n n+p

SARAM 2n–2 2n–2 2n–2, 2n+1

†

2n–2+p

External 4n–2+2nd 4n–2+2nd 4n–2+2nd 4n+1+2nd+p

†

If the operand and the code are in the same SARAM block

‡

If the LTD instruction is used with external memory, the data move will not occur. (The previous

product will be accumulated, and the TREG will be loaded.)

Example 1 LTD 126 ;(DP = 7: addresses 0380h–03FFh,

;PM = 0: no shift of product).

Before Instruction After Instruction

Data Memory Data Memory

3FEh 62h 3FEh 62h

Data Memory Data Memory

3FFh 0h 3FFh 62h

TREG 3h TREG 62h

PREG 0Fh PREG 0Fh

ACC X 5h ACC 0 14h

Cycles
