TMP104
SBOS564A –NOVEMBER 2011– REVISED NOVEMBER 2011
www.ti.com
PIN CONFIGURATION
YFF PACKAGE
WCSP-4 (DSBGA-4)
(TOP VIEW)
PIN DESCRIPTIONS
PIN
NO. NAME DESCRIPTION
A1 V+ Supply voltage
A2 GND Ground
B1 TX Serial data output pin (push-pull output)
B2 RX Serial data input pin
