TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 4-12. ARMWAIT Register Bit Descriptions
BIT NAME DESCRIPTION
31:1 RESERVED Reserved. Read returns "0".
ARM TCM RAM Wait State Configuration.
0 RAMWAIT 0 = TCM RAM wait state disabled.
1 = TCM RAM wait state enabled.
98 Device Configurations Copyright © 2009–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
