4.3.2.3 Video and TSIF Clock Disable
The Video Source Clock Disable (VSCLKDIS) register allows the user to disable the selected Video
(VPIF), TSIF, and CRGEN module input clocks.
Note: To ensure glitch-free operation, the clock should be disabled before changing the clock source
frequency or muxing via the VIDCLKCTL and TSIFCTL.
31 16
RESERVED
R-0000 0000 0000 0000
15 12 11 10 9 8 7 6 5 4 3 2 1 0
RESERVED VID3 VID2 VID1 VID0 TSIFCNT1 TSIFCNT0 TSIFTX1 TSIFTX0 TSIFRX1 TSIFRX0 CRG1 CRG0
R-0000 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Figure 4-4. VSCLKDIS Register [0x01C4 006C]
Table 4-6. VSCLKDIS Register Bit Descriptions
BIT NAME DESCRIPTION
31:12 RESERVED Reserved. Read returns "0".
VPIF Channel 3 Clock Disable.
11 VID3 0 = Clock enabled.
1 = Clock disabled.
VPIF Channel 2 Clock Disable.
10 VID2 0 = Clock enabled.
1 = Clock disabled.
VPIF Channel 1 Clock Disable.
9 VID1 0 = Clock enabled.
1 = Clock disabled.
VPIF Channel 0 Clock Disable.
8 VID0 0 = Clock enabled.
1 = Clock disabled.
TSIF1 Counter Clock Disable.
7 TSIFCNT1 0 = Clock enabled.
1 = Clock disabled.
TSIF0 Counter Clock Disable.
6 TSIFCNT0 0 = Clock enabled.
1 = Clock disabled.
TSIF1 Transmit Clock Disable.
5 TSIFTX1 0 = Clock enabled.
1 = Clock disabled.
TSIF0 Transmit Clock Disable.
4 TSIFTX0 0 = Clock enabled.
1 = Clock disabled.
TSIF1 Receive Clock Disable.
3 TSIFRX1 0 = Clock enabled.
1 = Clock disabled.
TSIF0 Receive Clock Disable.
2 TSIFRX0 0 = Clock enabled.
1 = Clock disabled.
CRGEN1 Clock Disable.
1 CRG1 0 = Clock enabled.
1 = Clock disabled.
CRGEN0 Clock Disable.
0 CRG0 0 = Clock enabled.
1 = Clock disabled.
