TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
4.3.2 Clock Control
This section describes the following registers: the VPIF (Video)/TSIF clock control and clock disable
registers and the Clock and Oscillator control register.
4.3.2.1 Video Clock Control Register
The Video Clock Control (VIDCLKCTL) register allows the user to select/control the clock muxing for the
video channels' (i.e., channels 1, 2, and 3) output clock source.
31 16
RESERVED
R-0000 0000 0000 0000
15 14 12 11 10 8 7 5 4 3 0
RSV VCH3CLK RSV VCH2CLK RESERVED VCH1CLK RESERVED
R-0 R/W-111 R-0 R/W-110 R-000 R/W-1 R-0000
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Figure 4-2. VIDCLKCTL Register [0x01C4 0038]
Table 4-4. VIDCLKCTL Register Bit Descriptions
BIT NAME DESCRIPTION
31:15 RESERVED Reserved. Read returns "0".
Video Channel 3 Clock Source.
This field selects the clock source for the Channel 3 output source clock.
000 = CRG0_VCXI (external pin)
001 = CRG1_VCXI (external pin)
010 = SYSCLK8 (PLLC1)
14:12 VCH3CLK
011 = AUXCLK (PLLC1)
100 = VP_CLKIN0 (external pin)
101 = STC_CLKIN (external pin)
110 = VP_CLKIN2 (external pin)
111 = VP_CLKIN3 (external pin)
11 RSV Reserved. Read returns "0".
Video Channel 2 Clock Source.
This field selects the clock source for the Channel 2 output source clock.
000 = CRG0_VCXI (external pin)
001 = CRG1_VCXI (external pin)
010 = SYSCLK8 (PLLC1)
10:8 VCH2CLK
011 = AUXCLK (PLLC1)
100 = VP_CLKIN0 (external pin)
101 = STC_CLKIN (external pin)
110 = VP_CLKIN2 (external pin)
111 = Reserved
7:5 RESERVED Reserved. Read returns "0".
Video Channel 1 Clock Source.
This bit selects the clock source for the Channel 1 input clock.
4 VCH1CLK
0 = VP_CLKIN0 (external pin)
1 = VP_CLKIN1 (external pin)
3:0 RESERVED Reserved. Read returns "0".
