4.3 Clock Considerations
Global device and local peripheral clocks are controlled by the PLL Controllers (PLLC1 and PLLC2) and
the Power and Sleep Controller (PSC). In addition, the System Module Video Clock Control (VIDCLKCTL),
TSIF Control (TSIFCTL), and Clock and Oscillator Control (CLKCTL) registers configure the clock sources
to the VPIF, TSIF, CRGEN peripherals, and the Auxiliary Oscillator.
The selected Video, TSIF, and CRGEN module input clocks are disabled using the System Module Video
Source Clock Disable (VSCLKDIS) register. Note: To ensure glitch-free operation, the clock should be
disabled before changing the clock source frequency or muxing via the VIDCLKCTL and TSIFCTL.
4.3.1 Clock Configurations after Device Reset
After device reset, the user is responsible for programming the PLL Controllers (PLLC1 and PLLC2) and
the Power and Sleep Controller (PSC) to bring the device up to the desired clock frequency and the
desired peripheral clock state (clock gating or not).
For additional power savings, some of the DM6467T peripherals support clock gating within the peripheral
boundary. For more details on clock gating and power saving features supported by a specific peripheral,
see the peripheral-specific reference/user's guides [listed/linked in the TMS320DM646x DMSoC
Peripherals Overview Reference Guide (literature number SPRUEQ0)].
4.3.1.1 Device Clock Frequency
The DM6467T defaults to PLL bypass mode. If the ROM bootloader is selected (BTMODE[3:0] ≠ 0100),
the bootloader code programs PLLC1 and PLLC2.
Section 4.4.1, Boot Modes discusses the different boot modes in more detail.
The user must adhere to the various clock requirements when programming the PLLC1 and PLLC2:
• PLL multiplier and frequency ranges. For more details on PLL multiplier and frequency ranges, see
Section 7.5.1, PLL1 and PLL2.
4.3.1.2 Module Clock State
The clock and reset state for each of the modules is controlled by the Power and Sleep Controller (PSC).
Table 4-3 shows the default state of each module after a device-level global reset. The DM6467T device
has four different module states—Enable, Disable, SyncReset, or SwRstDisable. For more information on
the definitions of the module states, the PSC, and PSC programming, see Section 7.3.5, Power and Sleep
Controller (PSC) and the TMS320DM646x DMSoC ARM Subsystem Reference Guide (literature number
SPRUEP9).
