TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
3 Device Overview
3.1 Device Characteristics
Table 3-1 provides an overview of the TMS320DM6467T SoC. The table shows significant features of the
device, including the capacity of on-chip RAM, peripherals, internal peripheral bus frequency relative to the
C64x+ DSP, and the package type with pin count.
Table 3-1. Characteristics of the DM6467T Processor
HARDWARE FEATURES DM6467T
DDR2 Memory Controller DDR2 (Up to 400-MHz, 16/32-bit bus width)
Asynchronous (8/16-bit bus width) RAM, Flash
Asynchronous EMIF (EMIFA)
(NOR, NAND)
64 independent channels
EDMA
8 QDMA channels
2 64-Bit General Purpose (each configurable as 2
Timers separate 32-bit timers)
1 64-Bit Watchdog
3 (with SIR, MIR, CIR support and RTS/CTS flow
UART control)
(UART0 Supports Modem Interface)
SPI 1 (supports 2 slave devices)
I
2
C 1 (Master/Slave)
2 (one transmit/receive with 4 serializers,
Multichannel Audio Serial Port (McASP) one DIT transmit only with 1 serializer for S/PDIF
output)
10/100/1000 Ethernet MAC with Management Data
1 (with MII/GMII Interface)
Input/Output (MDIO)
Peripherals
VLYNQ 1
Not all peripherals pins are General-Purpose Input/Output Port (GPIO) Up to 33 pins
available at the same time
PWM 2 outputs
(for more detail, see the
ATA 1 (ATA/ATAPI-6)
Device Configurations
section).
PCI 1 (32-bit, 66 MHz)
HPI 1 (16-/32-bit multiplexed address/data)
1 [horizontal and vertical downscaling,
VDCE
chroma conversion (4:2:2↔4:2:0)]
Clock Recovery Generator (CRGEN) 1
Power Sleep Controller (PSC) 1 (peripheral/module clock gating)
2 8-bit BT.656 capture channels or
1 16-bit Y/C capture channel or
150-MHz Configurable Video Port Interface (VPIF) 1 8-/10-/12-bit raw video capture channel and
2 8-bit BT.656 display channels or
1 16-bit Y/C display channel
MPEG transport stream interface
1 with 8-bit parallel or serial input and output
Transport Stream Interface (TSIF) 1 with serial-only input and output
Each with corresponding clock recovery generator
(CRGEN) for external VCXO control.
High- and Full-Speed Device
USB 2.0
(1)
High-, Full-, and Low-Speed Host
(1) USB2.0 is not supported on -1G parts that are dated prior to May 1, 2010. See the TMS320DM6467T Silicon Errata (Literature Number:
SPRZ307) for more details on how to decode the date from package markings.
