Table 3-28. ATA Terminal Functions
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
ATA
ATA is enabled by the PINMUX0.ATAEN =1 (and PCIEN = 0). For more detailed information on the ATA pin muxing, see Section 4.7.3.1,
PCI, HPI, EMIFA, and ATA Pin Muxing.
PCI_CBE0/
IPU This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
ATA_CS0 / F4 I/O/Z
DV
DD33
When ATA is enabled, this pin is ATA chip select 0 output, ATA_CS0 (O/Z).
GP[33]/EM_A[18]
PCI_CBE1/
IPU This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
ATA_CS1 / C2 I/O/Z
DV
DD33
When ATA is enabled, this pin is ATA chip select 1 output, ATA_CS1 (O/Z).
GP[32]/EM_A[19]
PCI_RSV4/ DIOW / IPU This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
A11 I/O/Z
GP[20]/EM_WAIT4 DV
DD33
When ATA is enabled, this pin is the ATA write strobe output, DIOW (O/Z).
PCI_RSV3/ DIOR / IPU This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
E10 I/O/Z
GP[19]/EM_WAIT5 DV
DD33
When ATA is enabled, this pin is the ATA read strobe output, DIOR (O/Z).
PCI_RSV5/IORDY/ IPU This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
D11 I/O/Z
GP[21]/EM_WAIT3 DV
DD33
When ATA is enabled, this pin is ATA I/O ready, IORDY (I).
PCI_RST/
IPD This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
DA2/ C10 I/O/Z
DV
DD33
When ATA is enabled, this pin is ATA address bit 2, DA2 (O/Z).
GP[13]/EM_A[22]
PCI_RSV0/DA1/ IPD This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
A9 I/O/Z
GP[16]/EM_A[21] DV
DD33
When ATA is enabled, this pin is ATA address bit 1, DA1 (O/Z).
PCI_RSV1/DA0/ IPD This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
E9 I/O/Z
GP[17]/EM_A[20] DV
DD33
When ATA is enabled, this pin is ATA address bit 0, DA0 (O/Z).
PCI_RSV2/INTRQ/ IPD This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
B10 I/O/Z
GP[18]/EM_RSV0 DV
DD33
When ATA is enabled, this pin is the ATA interrupt request input, INTRQ (I).
PCI_REQ/
IPU This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
DMARQ/ B9 I/O/Z
DV
DD33
When ATA is enabled, this pin is the ATA DMA request input, DMARQ (I).
GP[11]/EM_CS5
PCI_GNT/ This pin is multiplexed between PCI, ATA, GPIO, and EMIFA.
IPU
DMACK / D10 I/O/Z When ATA is enabled, this pin is the ATA DMA acknowledge output, DMACK
DV
DD33
GP[12]/EM_CS4 (O/Z).
PCI_IDSEL/ This pin is multiplexed between PCI, ATA, and EMIFA.
IPU
HDDIR/ E8 I/O/Z When ATA is enabled, this pin is the data direction indicator for external buffer
DV
DD33
EM_R/W control, HDDIR (O/Z).
(1) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(2) IPD = Internal pulldown, IPU = Internal pullup. For more detailed information on pullup/pulldown resistors and situations where external
pullup/pulldown resistors are required, see Section 4.8.1, Pullup/Pulldown Resistors.
(3) Specifies the operating I/O supply voltage for each signal
