TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 3-27. Timer 0, Timer 1, and Timer 2 Terminal Functions
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
Timer 0
IPD Timer0 lower input. This pin is the Timer0 input for 64-mode operation. For 32-bit
TINP0L Y7 I/O/Z
DV
DD33
timer operation, this pin is the input for the Timer0 lower 32-bit counter.
IPD Timer0 upper input. For 32-bit timer operation, this pin is the input for the Timer0
TINP0U AA6 I/O/Z
DV
DD33
upper 32-bit counter. Not used for Timer0 64-mode operation.
IPD Timer0 lower output. This pin is the Timer0 output for 64-mode operation. For 32-bit
TOUT0L W8 I/O/Z
DV
DD33
timer operation, this pin is the output for the Timer0 lower 32-bit counter.
IPD Timer0 upper output. For 32-bit timer operation, this pin is the output for the Timer0
TOUT0U W7 I/O/Z
DV
DD33
upper 32-bit counter. Not used for Timer0 64-mode operation.
Timer 1
IPD Timer1 lower input. This pin is the Timer1 input for 64-mode operation. For 32-bit
TINP1L Y6 I/O/Z
DV
DD33
timer operation, this pin is the input for the Timer1 lower 32-bit counter.
IPD Timer1 lower output. This pin is the Timer1 output for 64-mode operation. For 32-bit
TOUT1L AA5 I/O/Z
DV
DD33
timer operation, this pin is the output for the Timer1 lower 32-bit counter.
IPD Timer1 upper output. For 32-bit timer operation, this pin is the output for the Timer1
TOUT1U AB4 I/O/Z
DV
DD33
upper 32-bit counter. Not used for Timer1 64-mode operation.
WATCHDOG TIMER (Timer 2)
IPD
TOUT2 Y5 I/O/Z Watchdog timer output.
DV
DD33
(1) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(2) IPD = Internal pulldown, IPU = Internal pullup. For more detailed information on pullup/pulldown resistors and situations where external
pullup/pulldown resistors are required, see Section 4.8.1, Pullup/Pulldown Resistors.
(3) Specifies the operating I/O supply voltage for each signal
