Table 3-24. UART1 Terminal Functions
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
UART1 WITH FLOW CONTROL (PINMUX1.UART1CTL = 00)
Actual UART1 pin functions are determined by the PINMUX0 and PINMUX1 register bit settings. For more details, see
Section 4.7.3, Pin Multiplexing.
This pin is multiplexed between UART1, TSIF0, and GPIO.
URXD1/
IPD When UART1 UART functional muxing is selected (PINMUX1.UART1CTL = 0x)
TS0_DIN7/ Y18 I/O/Z
DV
DD33
and TSIF0 serial input is not enabled (PINMUX0.PTSIMUX ≠ 11), this pin is
GP[23]
UART1 receive data, URXD1 (I).
UTXD1/ This pin is multiplexed between UART1, TSIF0, and GPIO.
URCTX1/ IPD When UART1 UART functional muxing is selected (PINMUX1.UART1CTL = 0x)
AB19 I/O/Z
TS0_DOUT7/ DV
DD33
and TSIF0 serial output is not enabled (PINMUX0.PTSIMUX ≠ 11), this pin is
GP[24] UART1 transmit data, UTXD1 (O/Z).
This pin is multiplexed between UART1, TSIF0, and GPIO.
URTS1 /UIRTX1/
IPU When UART1 UART with flow control muxing is selected (PINMUX1.UART1CTL =
TS0_WAITO/ AA18 I/O/Z
DV
DD33
00) and TSIF0 input is not enabled (PINMUX0.PTSIMUX ≠ 0x), this pin is UART1
GP[25]
request-to-send, URTS1 (O/Z).
This pin is multiplexed between UART1, TSIF0, and GPIO.
UCTS1 /USD1
IPU When UART1 UART with flow control muxing is selected (PINMUX1.UART1CTL =
TS0_EN_WAITO/ Y17 I/O/Z
DV
DD33
00) and TSIF0 input is not enabled (PINMUX0.PTSIMUX ≠ 0x), this pin is UART1
GP[26]
clear-to-send, UCTS1 (I).
UART1 WITHOUT FLOW CONTROL (PINMUX1.UART1CTL = 01)
This pin is multiplexed between UART1, TSIF0, and GPIO.
URXD1/
IPD When UART1 UART functional muxing is selected (PINMUX1.UART1CTL = 0x)
TS0_DIN7/ Y18 I/O/Z
DV
DD33
and TSIF0 serial input is not enabled (PINMUX0.PTSIMUX ≠ 11), this pin is
GP[23]
UART1 receive data, URXD1 (I).
UTXD1/ This pin is multiplexed between UART1, TSIF0, and GPIO.
URCTX1/ IPD When UART1 UART functional muxing is selected (PINMUX1.UART1CTL = 0x)
AB19 I/O/Z
TS0_DOUT7/ DV
DD33
and TSIF0 serial output is not enabled (PINMUX0.PTSIMUX ≠ 11), this pin is
GP[24] UART1 transmit data, UTXD1 (O/Z).
UART1 IrDA/CIR FUNCTION (PINMUX1.UART1CTL = 10)
This pin is multiplexed between UART1, TSIF0, and GPIO.
URXD1/
IPD When UART1 IrDA/CIR functional muxing is selected (PINMUX1.UART1CTL = 10)
TS0_DIN7/ Y18 I/O/Z
DV
DD33
and TSIF0 serial input is not enabled (PINMUX0.PTSIMUX ≠ 11), this pin is
GP[23]
UART1 receive data, URXD1 (I).
This pin is multiplexed between UART1, TSIF0, and GPIO.
UTXD1/URCTX1/
IPD When UART1 IrDA/CIR functional muxing is selected (PINMUX1.UART1CTL = 10)
TS0_DOUT7/ AB19 I/O/Z
DV
DD33
and TSIF0 serial output is not enabled (PINMUX0.PTSOMUX ≠ 11), this pin is
GP[24]
UART1 CIR transmit data, URCTX1 (O/Z).
This pin is multiplexed between UART1, TSIF0, and GPIO.
URTS1/UIRTX1/
IPU When UART1 IrDA/CIR functional muxing is selected (PINMUX1.UART1CTL = 10)
TS0_WAITO/ AA18 I/O/Z
DV
DD33
and TSIF0 input is not enabled (PINMUX0.PTSIMUX = 0x), this pin is UART1 IrDA
GP[25]
transmit data, UIRTX1 (O/Z).
This pin is multiplexed between UART1, TSIF0, and GPIO.
UCTS1/USD1/
IPU When UART1 IrDA/CIR functional muxing is selected (PINMUX1.UART1CTL = 10)
TS0_EN_WAITO/ Y17 I/O/Z
DV
DD33
and TSIF0 input is not enabled (PINMUX0.PTSIMUX = 0x), this pin is UART1 IrDA
GP[26]
tranceiver control, USD1 (O/Z).
(1) IPD = Internal pulldown, IPU = Internal pullup. For more detailed information on pullup/pulldown resistors and situations where external
pullup/pulldown resistors are required, see Section 4.8.1, Pullup/Pulldown Resistors.
(2) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(3) Specifies the operating I/O supply voltage for each signal
