TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 3-23. UART0 Terminal Functions
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
Actual UART0 pin functions are determined by the PINMUX0 and PINMUX1 register bit settings. For more details, see
Section 4.7.3, Pin Multiplexing.
UART0 WITH MODEM CONTROL (PINMUX1.UART0CTL = 00)
This pin is multiplexed between UART0 and TSIF1.
URXD0/ IPD When UART0 UART functional muxing is selected (PINMUX1.UART0CTL = 0x)
AB13 I
TS1_DIN DV
DD33
and TSIF1 input on UART0 muxing is not enabled (PINMUX0.TSSIMUX ≠ 01), this
pin is UART0 receive data, URXD0 (I).
This pin is multiplexed between UART0 and TSIF1.
UTXD0/
IPD When UART0 UART functional muxing is selected (PINMUX1.UART0CTL = 0x)
URCTX0/ Y13 I/O/Z
DV
DD33
and TSIF1 input on UART0 muxing is not enabled (PINMUX0.TSSIMUX ≠ 01), this
TS1_PSTIN
pin is UART0 transmit data, UTXD0 (O/Z).
This pin is multiplexed between UART0 and TSIF1.
URTS0 /
IPU When UART0 UART functional muxing is selected (PINMUX1.UART0CTL = 0x)
UIRTX0/ AA13 I/O/Z
DV
DD33
and TSIF1 input on UART0 muxing is not enabled (PINMUX0.TSSIMUX ≠ 01), this
TS1_EN_WAITO
pin is the UART0 request-to-send signal, URTS0 (O/Z).
This pin is multiplexed between UART0 and TSIF1.
IPU When UART0 UART functional muxing is selected (PINMUX1.UART0CTL = 0x)
UCTS0 / USD0 AC12 I/O/Z
DV
DD33
and TSIF1 input on UART0 muxing is not enabled (PINMUX0.TSSIMUX ≠ 01), this
pin is the UART0 clear-to-send signal, UCTS0 (I).
This pin is multiplexed between UART0, TSIF0, and GPIO.
UDTR0 /
IPU When UART0 UART with modem functional muxing is selected
TS0_ENAO/ Y12 I/O/Z
DV
DD33
(PINMUX1.UART0CTL = 00) and TSIF0 output muxing is not enabled
GP[36]
(PINMUX0.PTSOMUX ≠ 1x), this pin is UART0 data-terminal-ready, UDTR0 (O/Z).
This pin is multiplexed between UART0, TSIF0, and GPIO.
UDSR0 /
IPU When UART0 UART with modem functional muxing is selected
TS0_PSTO/ AB11 I/O/Z
DV
DD33
(PINMUX1.UART0CTL = 00) and TSIF0 output muxing is not enabled
GP[37]
(PINMUX0.PTSOMUX ≠ 1x), this pin is UART0 data-set-ready, UDSR0 (I).
This pin is multiplexed between UART0, TSIF0, and GPIO.
UDCD0 /
IPU When UART0 UART with modem functional muxing is selected
TS0_WAITIN/ AA11 I/O/Z
DV
DD33
(PINMUX1.UART0CTL = 00) and TSIF0 output muxing is not enabled
GP[38]
(PINMUX0.PTSOMUX ≠ 1x), this pin is UART0 data-carrier-detect, UDCD0 (I).
This pin is multiplexed between UART0, GPIO, and TSIF1.
When UART0 UART with modem functional muxing is selected
URIN0 /GP[8]/ IPD
Y11 I/O/Z (PINMUX1.UART0CTL = 00) and TSIF1 output on UART/PWM muxing is not
TS1_WAITIN DV
DD33
enabled (PINMUX0.TSSOMUX ≠ 11), this pin is the UART0 ring indicator,
URIN0 (I).
UART0 WITHOUT MODEM CONTROL (PINMUX1.UART0CTL = 01)
This pin is multiplexed between UART0 and TSIF1.
URXD0/ IPD When UART0 UART functional muxing is selected (PINMUX1.UART0CTL = 0x)
AB13 I
TS1_DIN DV
DD33
and TSIF1 input on UART0 muxing is not enabled (PINMUX0.TSSIMUX ≠ 01), this
pin is UART0 receive data, URXD0 (I).
This pin is multiplexed between UART0 and TSIF1.
UTXD0/
IPD When UART0 UART functional muxing is selected (PINMUX1.UART0CTL = 0x)
URCTX0/ Y13 I/O/Z
DV
DD33
and TSIF1 input on UART0 muxing is not enabled (PINMUX0.TSSIMUX ≠ 01), this
TS1_PSTIN
pin is UART0 transmit data, UTXD0 (O/Z).
This pin is multiplexed between UART0 and TSIF1.
URTS0 /
IPU When UART0 UART functional muxing is selected (PINMUX1.UART0CTL = 0x)
UIRTX0/ AA13 I/O/Z
DV
DD33
and TSIF1 input on UART0 muxing is not enabled (PINMUX0.TSSIMUX ≠ 01), this
TS1_EN_WAITO
pin is UART0 request-to-send signal, URTS0 (O/Z).
When UART0 UART functional muxing is selected (PINMUX1.UART0CTL = 0x)
UCTS0 / IPU
AC12 I/O/Z and TSIF1 input on UART0 muxing is not enabled (PINMUX0.TSSIMUX ≠ 01), this
USD0 DV
DD33
pin is UART0 clear-to-send signal, UCTS0 (I).
(1) IPD = Internal pulldown, IPU = Internal pullup. For more detailed information on pullup/pulldown resistors and situations where external
pullup/pulldown resistors are required, see Section 4.8.1, Pullup/Pulldown Resistors.
(2) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(3) Specifies the operating I/O supply voltage for each signal
