TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 3-19. I2C Terminal Functions
SIGNAL
TYPE
(1)
OTHER
(2)
DESCRIPTION
NAME NO.
I2C
- I2C clock output SCL. For proper device operation, this pin must be pulled up via
SCL U5 I/O/Z
DV
DD33
external resistor.
- I2C bidirectional data signal SDA. For proper device operation, this pin must be
SDA U4 I/O/Z
DV
DD33
pulled up via external resistor.
(1) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(2) Specifies the operating I/O supply voltage for each signal
Table 3-20. SPI Terminal Functions
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
SPI
IPD
SPI_CLK V1 I/O/Z SPI clock
DV
DD33
IPD
SPI_EN T5 I/O/Z SPI device enable
DV
DD33
IPD
SPI_CS0 T4 I/O/Z SPI chip select 0
DV
DD33
IPD
SPI_CS1 U3 I/O/Z SPI chip select 1
DV
DD33
IPD
SPI_SOMI R5 I/O/Z SPI slave out, master in data pin
DV
DD33
IPD
SPI_SIMO P5 I/O/Z SPI slave in, master out data pin
DV
DD33
(1) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(2) IPD = Internal pulldown, IPU = Internal pullup. For more detailed information on pullup/pulldown resistors and situations where external
pullup/pulldown resistors are required, see Section 4.8.1, Pullup/Pulldown Resistors.
(3) Specifies the operating I/O supply voltage for each signal
Copyright © 2009–2012, Texas Instruments Incorporated Device Overview 57
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
