TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 3-17. Transport Stream Interface 0 (TSIF0) Terminal Functions
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
TSIF0 PARALLEL INPUT (PINMUX0.PTSIMUX = 10)
IPD
TS0_CLKIN AC19 I TSIF0 receive clock input (I).
DV
DD33
This pin is multiplexed between UART1, TSIF0, and GPIO.
UCTS1/USD1/
IPU When TSIF0 input is enabled (PINMUX0.PTSIMUX = 1x), in synchronous
TS0_EN_WAITO/ Y17 I/O/Z
DV
DD33
mode, this pin is the data enable indicator (I) or in asynchronous mode, this
GP[26]
pin is the wait output (O/Z), TS0_EN_WAITO.
This pin is multiplexed between UART1, TSIF0, and GPIO.
URTS1/UIRTX1/ IPU When TSIF0 input is enabled (PINMUX0.PTSIMUX = 1x), in asynchronous
AA18 I/O/Z
TS0_WAITO/GP[25] DV
DD33
mode, this pin is the wait output, TS0_WAITO (O/Z).
This TSIF pin function is not used in synchronous mode.
This pin is multiplexed between UART2, TSIF0, and GPIO.
URTS2/UIRTX2/ IPU
AC20 I/O/Z When TSIF0 input is enabled (PINMUX0.PTSIMUX = 1x), this pin is the
TS0_PSTIN/GP[41] DV
DD33
packet start input indicator, TS0_PSTIN (I).
VP_DIN15_VP_VSYNC/
AC18
TS0_DIN7
VP_DIN14_VP_HSYNC/
AA17
TS0_DIN6
VP_DIN13_FIELD/
AB17
TS0_DIN5
VP_DIN12/
AC17
These pins are multiplexed between the VPIF and TSIF0.
TS0_DIN4
IPD
I/O/Z When TSIF0 parallel input mux mode is enabled (PINMUX0.PTSIMUX = 10),
DV
DD33
VP_DIN11/
these pins are input data bits TS0_DIN[7:0] (I).
Y16
TS0_DIN3
VP_DIN10/
AA16
TS0_DIN2
VP_DIN9/
AB16
TS0_DIN1
VP_DIN8/
AC16
TS0_DIN0
TSIF0 SERIAL INPUT (PINMUX0.PTSIMUX = 11)
IPD
TS0_CLKIN AC19 I TSIF0 receive clock input (I).
DV
DD33
This pin is multiplexed between UART1, TSIF0, and GPIO.
UCTS1/USD1/
IPU When TSIF0 input is enabled (PINMUX0.PTSIMUX = 1x), in synchronous
TS0_EN_WAITO/ Y17 I/O/Z
DV
DD33
mode, this pin is the data enable indicator (I) or in asynchronous mode, this
GP[26]
pin is the wait output (O/Z), TS0_EN_WAITO.
This pin is multiplexed between UART2, TSIF0, and GPIO.
URTS2/UIRTX2/ IPU When TSIF0 input is enabled (PINMUX0.PTSIMUX = 1x), in
AC20 I/O/Z
TS0_PSTIN/GP[41] DV
DD33
synchronous/asynchronous modes, this pin is the packet start input indicator,
TS0_PSTIN (I).
This pin is multiplexed between UART1, TSIF0, and GPIO.
URXD1/ IPD When TSIF0 serial input mux mode is enabled (PINMUX0.PTSIMUX = 11), in
Y18 I/O/Z
TS0_DIN7/GP[23] DV
DD33
synchronous/asynchronous modes, this pin is the serial input data bit (I),
TS0_DIN7(I).
(1) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(2) IPD = Internal pulldown, IPU = Internal pullup. For more detailed information on pullup/pulldown resistors and situations where external
pullup/pulldown resistors are required, see Section 4.8.1, Pullup/Pulldown Resistors.
(3) Specifies the operating I/O supply voltage for each signal
Copyright © 2009–2012, Texas Instruments Incorporated Device Overview 53
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
