TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 3-16. Video-Port Interface (VPIF) Terminal Functions
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
VIDEO-PORT INTERFACE (VPIF) – CAPTURE
IPD
VP_CLKIN0 AC13 I VPIF capture channel 0 input clock (I).
DV
DD33
IPD
VP_CLKIN1 AB18 I VPIF capture channel 1 input clock (I).
DV
DD33
This pin is multiplexed between the VPIF and TSIF0.
VP_DIN15_VP_VSYNC/ IPD
AC18 I When used for the VPIF, this pin is capture data bit 15 or the vertical sync
TS0_DIN7 DV
DD33
input, VP_DIN15_VSYNC (I).
This pin is multiplexed between the VPIF and TSIF0.
VP_DIN14_VP_HSYNC/ IPD
AA17 I When used for the VPIF, this pin is capture data bit 14 or the horizontal sync
TS0_DIN6 DV
DD33
input, VP_DIN14_HSYNC (I).
This pin is multiplexed between the VPIF and TSIF0.
VP_DIN13_FIELD/ IPD
AB17 I When used for the VPIF, this pin is capture data bit 13 or the field indicator
TS0_DIN5 DV
DD33
input, VP_DIN13_FIELD (I).
VP_DIN12/
AC17
TS0_DIN4
VP_DIN11/
Y16
TS0_DIN3
VP_DIN10/ IPD These pins are multiplexed between the VPIF and TSIF0.
AA16 I
TS0_DIN2 DV
DD33
When used for the VPIF, these pins are capture data bits, VP_DIN[12:8] (I).
VP_DIN9/
AB16
TS0_DIN1
VP_DIN8/
AC16
TS0_DIN0
VP_DIN7/
TS0_DOUT7/ Y14
TS1_DIN
VP_DIN6/
TS0_DOUT6/ AA14
TS1_PSTIN
IPD These pins are multiplexed between the VPIF, TSIF0, and TSIF1.
I/O/Z
DV
DD33
When used for the VPIF, these pins are capture data bits, VP_DIN[7:4] (I).
VP_DIN5/
TS0_DOUT5/ AB14
TS1_EN_WAITO
VP_DIN4/
TS0_DOUT4/ AC14
TS1_WAITO
VP_DIN3/
Y15
TS0_DOUT3
VP_DIN2/
AA15
TS0_DOUT2
IPD These pins are multiplexed between the VPIF and TSIF0.
I/O/Z
DV
DD33
When used for the VPIF, these pins are capture data bits, VP_DIN[3:0] (I).
VP_DIN1/
AB15
TS0_DOUT1
VP_DIN0/
AC15
TS0_DOUT0
VIDEO-PORT INTERFACE (VPIF) – DISPLAY
IPD
VP_CLKIN2 Y10 I VPIF display channel 2 source input clock (I).
DV
DD33
This pin is multiplexed between the VPIF and TSIF1.
VP_CLKIN3/ IPD
AC9 I/O/Z When used for VPIF, this pin is display channel 3 source clock, VP_CLKIN3
TS1_CLKO DV
DD33
(I).
-
VP_CLKO2 AA9 O/Z VPIF display channel 2 output clock (O/Z).
DV
DD33
(1) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(2) IPD = Internal pulldown, IPU = Internal pullup. For more detailed information on pullup/pulldown resistors and situations where external
pullup/pulldown resistors are required, see Section 4.8.1, Pullup/Pulldown Resistors.
(3) Specifies the operating I/O supply voltage for each signal
Copyright © 2009–2012, Texas Instruments Incorporated Device Overview 51
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
