Table 3-15. USB Terminal Functions
SIGNAL
OTHER
(2) (3)
TYPE
(1)
DESCRIPTION
(4)
NAME NO.
USB 2.0
USB_DP A19 A I/O USB bidirectional Data Differential signal pair [positive/negative].
When the USB peripheral is not used, the USB_DP signal should be pulled up
USB_DN A20 A I/O
(high) and the USB_DN signal should be pulled down (low) via a 10-kΩ resistor.
USB current reference output. When the USB peripheral is used, this pin must be
connected via a 10-kΩ ±1% resistor to USB_V
SSREF
.
USB_R1 D18 A I/O
(4)
When the USB peripheral is not used, this pin must be connected via a 10-kΩ
resistor to USB_V
SSREF
.
This pin is multiplexed between USB and GPIO.
USB_DRVVBUS/ IPD When this pin is used as USB_DRVVBUS (PINMUX0.VBUSDIS = 0), and the USB
B18 I/O/Z
GP[22] DV
DD33
Controller is operating as a Host (USBCTL.USBID = 0 and Session is in progress),
this signal is used by the USB Controler to enable the external VBUS charge pump.
Ground for reference current. This pin must be connected via a 10-kΩ ±1% resistor
to USB_R1.
USB_V
SSREF
C18 GND
(4)
When the USB peripheral is not used, the USB_V
SSREF
signal should be connected
to V
SS
.
Analog 3.3 V power supply for USB PHY.
USB_V
DDA3P3
F18 S
(4)
When the USB peripheral is not used, the USB_V
DDA3P3
signal should be
connected to DV
DD33
.
1.8-V I/O power supply for USB PHY.
USB_V
DD1P8
E18 S
(4)
When the USB peripheral is not used, the USB_V
DD1P8
signal should be connected
to 1.8-V power supply.
Core power supply LDO output for USB PHY. This pin must be connected via a 1-
μF capacitor to V
SS
.
USB_V
DDA1P2LDO
E17 S
(4)
When the USB peripheral is not used, the USB_V
DDA1P2LDO
signal should still be
connected via a 1-μF capacitor to V
SS
.
(1) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(2) IPD = Internal pulldown, IPU = Internal pullup. For more detailed information on pullup/pulldown resistors and situations where external
pullup/pulldown resistors are required, see Section 4.8.1, Pullup/Pulldown Resistors.
(3) Specifies the operating I/O supply voltage for each signal
(4) For more information, see the Recommended Operating Conditions table
