TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 3-14. HPI Terminal Functions (continued)
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
PCI_IRDY/
IPU This pin is multiplexed between PCI, HPI, and EMIFA.
HRDY / A3 I/O/Z
DV
DD33
In HPI mode, this pin is the HPI host ready output from DSP to host, HRDY (O/Z).
EM_A[17]/(CLE)
PCI_FRAME/ IPU This pin is multiplexed between PCI, HPI, and EMIFA.
D6 I/O/Z
HINT /EM_BA[0] DV
DD33
In HPI mode, this pin is the HPI host interrupt output, HINT (O/Z).
Copyright © 2009–2012, Texas Instruments Incorporated Device Overview 49
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
